IM06B30AC1

600V 30A Mini IPM

Infineon

IM06B30AC1 Features

* Package

* Fully isolated dual in-line molded module

* Lead-free terminal plating; RoHS compliant Inverter

* 650 V TRENCHSTOP™ IGBT7 T7

* 600 V rugged SOI gate driver technology with stability against transient and negative voltage

* Allowable negative VS poten

IM06B30AC1 General Description

The CIPOS™ Mini IPM product family offers the chance for integrating various power and control components to increase reliability and optimize PCB size and system cost. It is designed to control 3-phase motors in variable speed drives. The package concept is specially adapted to power applications, .

IM06B30AC1 Datasheet (673.36 KB)

IM06B30AC1 Datasheet Preview — Preview of IM06B30AC1 PDF

Datasheet Details

Part number:

IM06B30AC1

Manufacturer:

Infineon ↗

File Size:

673.36 KB

Description:

600v 30a mini ipm.
