IPP70N12S3-11 Datasheet, Transistor, Infineon

IPP70N12S3-11 Features

• Transistor
• OptiMOSTM - power MOSFET for automotive applications VDS RDS(on),max (SMD version) ID 120 V 11.3 mW 70 A
• N-channel - Enhancement mode
• Automotive AEC Q1

PDF File Details

Part number:

IPP70N12S3-11

Manufacturer:

Infineon ↗

File Size:

825.71kb

Download:

📄 Datasheet

Description:

Power transistor.

IPP70N12S3-11 Application

• Applications VDS RDS(on),max (SMD version) ID 120 V 11.3 mW 70 A
• N-channel - Enhancement mode
• Automotive AEC Q101 qualified
