IP6818 - TWS Bluetooth Earphone Charging Box SOC

Datasheet Summary

Description

IP6818 is a multi-functional power management SOC for total solution on TWS Bluetooth Earphone Charging Box.

It integrates with Qi wireless power receiver, 5V-boost converter, lithium battery charging management and battery level indicators.

Features

  • Discharge.
  • Output capacity: 5V/300mA.
  • Up to 93%@5V/150mA discharge efficiency of synchronous switch.
  • Built-in power path management supports charging and discharging at the same time.
  • Charge.
  • Max 500mA linear charger, adjustable charging current.
  • Adjusts charging current automatically to adapt to different load capacity adapters.
  • Supports 4.20V, 4.30V 4.35V, 4.40V batteries.
  • Supports wireless power receiver compliant with Qi.
  • Battery indicators.

📥 Download Datasheet

Datasheet preview – IP6818

Datasheet Details

Part number IP6818
Manufacturer Injoinic
File Size 1.04 MB
Description TWS Bluetooth Earphone Charging Box SOC
Datasheet download datasheet IP6818 Datasheet
Additional preview pages of the IP6818 datasheet.

📁 Similar Datasheet

  • IP6809B - 7.5W/10W/15W wireless charging transmitter controller (ChipSourceTek)
  • IP6829 - wireless charging transmitter SOC (ChipSourceTek)
  • IP6833 - 5W wireless charging receiver (ChipSourceTek)
  • IP6505 - SOC IC (ChipSourceTek)
  • IP6520T - buck SOC (ChipSourceTek)
  • IP6525S - Buck SOC (ChipSourceTek)
  • IP6538 - High performance switching power supply secondary synchronous rectifier controller (INPOWER)
  • IP6648 - MOSFET (INPOWER)
Other Datasheets by Injoinic
  • IP6816 - TWS Bluetooth Earphone Charging Box SOC
  • IP6801 - Wireless Charging Transmitter Microcontroller
  • IP6802 - Wireless charging transmitter controller
  • IP6805S - Highly integrated 5W wireless charging transmitter controller
  • IP6805U - Wireless Power Transmitter
  • IP6806 - Wireless Power Transmitter
  • IP6808 - Wireless Power Transmitter Compliant
  • IP6809 - Multi-coil Wireless Power Transmitter Compliant

Full PDF Text Transcription

Click to expand full text
IP6818 TWS Bluetooth Earphone Charging Box SOC integrated with Qi wireless power reciever 1. Features  Discharge  Output capacity: 5V/300mA  Up to 93%@5V/150mA discharge efficiency of synchronous switch  Built-in power path management supports charging and discharging at the same time  Charge  Max 500mA linear charger, adjustable charging current  Adjusts charging current automatically to adapt to different load capacity adapters  Supports 4.20V, 4.30V 4.35V, 4.
