2N6454 Datasheet, Jfet, InterFET

2N6454 Features

• Jfet
• InterFET N0132L Geometry
• Low noise: 1.0 nV/√Hz typical
• High gain: 32mS typical
• Low gate leakage: 750fA typical @10V
• Typical IDSS: 25mA

PDF File Details

Part number:

2N6454

Manufacturer:

InterFET

File Size:

702.43kb

Download:

📄 Datasheet

Description:

N-channel jfet. The -25V InterFET 2N6453 and 2N6454 are targeted for sensitive amplifier stages for mid-frequencies designs. Gate leakages are typica

2N6454 Application

• Applications
• General: Amplifiers; Switches; Voltage regulators; NOTE: S/D pins are interchangeable Source Drain connections Oscillators;
