Part number: IR2110C
Manufacturer: International Rectifier
File Size: 437.80 KB
Datasheet: IR2110C_InternationalRectifier.pdf
Description: High and Low Side Driver

IR2110C Product details

Description

The IR2110/IR2113 are high voltage, high speed power MOSFET and IGBT drivers with independent high and low side referenced output channels.

Features

100 % Tested at Probec.
3.3V logic compatible.
Available in Chip Pack, Unsawn Wafer, Sawn on Film d Separate logic supply range from 3.3V to 20V.
Floating channel designed for bootstrap operation Logic and power ground ±5V offset Fully operational to +500V or +600V.
CMOS Schmitt-triggered inputs with pull-down Tolerant to negative transient voltage.
Cycle by cycle edge-triggered shutdown logic dV/dt immune.
Matched propagation delay.
