HS9-82C12RH - Radiation Hardened 8-Bit Input/Output Port

HS9-82C12RH Description

HS-82C12RH March 1996 Radiation Hardened 8-Bit Input/Output Port Functional Diagram DS1 DS2 STB CLR MD DATA LATCH AND BUFFER (8) CONTROL AND DEVICE S.
PIN DI0-DI7 DO0-DO7 DS1, DS2 MD STB INT CLR Data In Data Out Device Select Mode Strobe Interrupt Clear DESCRIPTION Description The Intersil HS-82C12R.

HS9-82C12RH Features

* Devices QML Qualified in Accordance with MIL-PRF-38535
* Detailed Electrical and Screening Requirements are Contained in SMD# 5962-95818 and Intersil’ QM Plan - Radiation Hardened CMOS Process - Total Dose 1 x 105 RAD (Si) - Transient Upset > 1 x 108 RAD (Si)/s - Latch-Up Immune EPI

📥 Download Datasheet

Preview of HS9-82C12RH PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
HS9-82C12RH
Manufacturer
Intersil Corporation
File Size
49.05 KB
Datasheet
HS9-82C12RH_IntersilCorporation.pdf
Description
Radiation Hardened 8-Bit Input/Output Port
