Part number:
S2MBF
Manufacturer:
Jingdao Microelectronics
File Size:
65.81 KB
Description:
Surface mount general purpose silicon rectifiers.
* For surface mounted applications
* Low profile package
* Glass Passivated Chip Junction
* Easy to pick and place
* Lead free in comply with EU RoHS 2011/65/EU directives MECHANICAL DATA
* Case: SMBF
* Terminals: Solderable per MIL-STD-750, Me
S2MBF
Jingdao Microelectronics
65.81 KB
Surface mount general purpose silicon rectifiers.
