JW1965C, JW1965A - Boost LEDDriver

JW1965C Description

JW1965A/JW1965B/JW1965C Boost LED Driver With Power Factor Correction Parameters Subject to Change Without Notice .
The JW®1965A/JW1965B/JW1965C (JW1965X series) is a constant current LED driver which applies to single stage Boost power factor corrected LED drivers.

JW1965C Features

* No auxiliary winding and VCC capacitor
* Supplied from output voltage directly
* High current accuracy of line and load regulation
* Internal compensation PFC technics
* Critical conduction mode
* High efficiency over wide operating range
* L

JW1965C Applications

* JW1965X series has multi-protection functions which largely enhance the safety and reliability of the system, including LED open protection, freewheeling diode open protection and overtemperature protection. Company’s Logo is Protected, “JW” and “JOULWATT” are Registered Trademarks of JoulWatt tech

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: JW1965C, JW1965A. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
JW1965C, JW1965A
Manufacturer
JoulWatt
File Size
965.46 KB
Datasheet
JW1965A-JoulWatt.pdf
Description
Boost LEDDriver
Note
This datasheet PDF includes multiple part numbers: JW1965C, JW1965A.
Please refer to the document for exact specifications by model.
