LM200WD3-TLC1 Datasheet - LG

LM200WD3-TLC1 HD + TFT LCD

ABSOLUTE MAXIMUM RATINGS ELECTRICAL SPECIFICATIONS ELECTRICAL CHARACTERISTICS INTERFACE CONNECTIONS LVDS characteristics SIGNAL TIMING SPECIFICATIONS SIGNAL TIMING WAVEFORMS COLOR INPUT DATA REFERNECE POWER SEQUENCE POWER DIP CONDITION OPTICAL SFECIFICATIONS RELIABILITY SAFETY EMC ITEM Page 1 2 3 4 .

LM200WD3 Liquid Crystal Display Product Specification Title BUYER MODEL General 20.0” HD+ TFT LCD on SUPPLIER MODEL SUFFIX www.jxlcd.com www.jxlcd.com C When you obtain standard approval, please use the above model name without suffix SIGNATURE ny DATE fid ( ) Preliminary Specification ( ) Final Specification APPROVED BY S.G. Hong / G.Manager REVIEWED BY D.G. Kim / Manager [C] Y.H. Hwang / Manager [M] M.S. Kang / Manager [P] PREPARED BY K.H. Oh / Engineer en LG D.

LM200WD3-TLC1 Features

* 20.0 inches (508.05mm) diagonal 462.8(H) x 272.0(V) x 10.2(D) mm(Typ.) 0.0922

* RGB(H)mm x 0.2766(V)mm 1600 horizontal By 900 vertical Pixels. RGB stripe arrangement LVDS 2Port 16.7M colors 250 cd/m2 ( Center 1Point, typ) R/L 170(Typ.), U/D 160(Typ.) Total TBD W(Typ.), (TBD W@VLCD , 9.9 W@IBL =
