SB8100-HE, SB820-HE - Schottky Barrier Rectifiers

SB8100-HE Description

SB820-HE thru SB8100-HE Schottky Barrier Rectifiers Reverse Voltage 20 to 100V Forward Current8.0A .

SB8100-HE Applications

* Guarding for over voltage protection
* High temperature soldering guaranteed: 260°C/10 seconds at terminals Mechanical Data Case : JEDEC DO-201AD, molded plastic over sky die Terminals : Plated axial leads, solderable per MIL-STD-750, Method 2026 Polarity : Color band denotes cathod

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: SB8100-HE, SB820-HE. Please refer to the document for exact specifications by model.
