LTC2145-12 Datasheet, Adcs, Linear Technology

LTC2145-12 Features

• Adcs n 2-Channel Simultaneously Sampling ADC n 70.6dB SNR n 89dB SFDR n Low Power: 183mW/144mW/109mW Total 92mW/72mW/55mW per Channel n Single 1.8V Supply n CMOS, DDR CMOS, or DDR LVDS Outpu

PDF File Details

Part number:

LTC2145-12

Manufacturer:

Linear Technology

File Size:

1.00MB

Download:

📄 Datasheet

Description:

Low power dual adcs. The LTC®2145-12/LTC2144-12/LTC2143-12 are 2-channel simultaneous sampling 12-bit A/D converters designed for digitizing high frequenc

LTC2145-12 Application

• Applications n Communications n Cellular Base Stations n Software Defined Radios n Portable Medical Imaging n Multi-Channel Data Acquisition n Nonde
