LTC3604

2.5A 15V Monolithic Synchronous Step-Down Regulator

Image Manufacturer B2B MPN Description Distributor Stock Quantity Price Buy Now
Distributor Analog Devices Inc LTC3604EUD-PBF IC REG BUCK ADJ 2.5A 16QFN DigiKey 4496 363 units
$4.86

LTC3604 Datasheet (384.48 KB)

Preview of LTC3604 PDF Datasheet

Datasheet Details

Part number:

LTC3604

Manufacturer:

Linear Technology

File Size:

384.48 KB

Description:

2.5a 15v monolithic synchronous step-down regulator

LTC3604 Features

* nn 3.6V to 15V Operating Input Voltage Range nn 2.5A Output Current nn Up to 95% Efficiency nn Very Low Duty Cycle Operation: 5% at 2.25MHz nn Adjustable Switching Frequency: 800kHz to 4MHz nn External Frequency Synchronization nn Current Mode Operation for Excellent Line and Load Transient Response

LTC3604 General Description

The LTC®3604 is a high efficiency, monolithic synchronous buck regulator using a phase-lockable controlled on-time, current mode architecture capable of supplying up to 2.5A of output current. The operating supply voltage range is from 3.6V to 15V, making it suitable for a wide range of power supply.
