LTC7003 Datasheet, Driver, Linear

LTC7003 Features

• Driver nn Wide Operating VIN: 3.5V to 60V nn 1Ω Pull-Down, 2.2Ω Pull-Up for Fast Turn-On and Turn-Off Times with 35ns Propagation Delays nn Internal Charge Pump for 100% Duty Cycle nn Short-Ci

PDF File Details

Part number:

LTC7003

Manufacturer:

Linear

File Size:

2.56MB

Download:

📄 Datasheet

Description:

Fast 60v protected high side nmos static switch driver. The LTC®7003 is a fast high side N-channel MOSFET gate driver that operates from input voltages up to 60V. It contains an internal ch

LTC7003 Application

• Applications nn Static Switch Driver nn Load and Supply Switch Driver nn Electronic Valve Driver nn High Frequency High Side Gate Driver DESCRIPTIO
