LP2064 10/100Base-TX Dual Port Transformer

10/100Base-TX Dual Port Transformer Modules Meets all IEEE standards including 350 H OCL with 8 mA bias Symmetrical TX and RX channels for auto MDI/MDIX capability For RoHS compliant parts add suffix NL RoHS NL peak solder rating 235          Link-PP Int’l Technology Part Number Pri Inductance (100KHz/0.1V @8mA) LP2064 350μH MIN Electrical Specifications 25   Operating Temperature 0 to 70 Leakage Inductance (1MHz/0.1V) Interwinding CAP (100 KHz/0.1V) 0.4μH MAX .

LP2064-Link-PP.pdf

This datasheet PDF includes multiple part numbers: LP2064, LP2064-Link. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

LP2064, LP2064-Link

Manufacturer:

Link-PP

File Size:

104.51 KB

Description:

10/100base-tx dual port transformer.

Note:

This datasheet PDF includes multiple part numbers: LP2064, LP2064-Link.
Please refer to the document for exact specifications by model.
