MASW-010612-TR3000 Datasheet, Switch, MA-COM

MASW-010612-TR3000 Features

• Switch
• Low Insertion Loss: 0.6 dB
• High P1dB: 36 dBm
• 0.5 micron GaAs pHEMT Process
• Fast Settling Speed for timing-sensitive applications
• 1.8 V

PDF File Details

Part number:

MASW-010612-TR3000

Manufacturer:

MA-COM

File Size:

614.55kb

Download:

📄 Datasheet

Description:

Gaas sp3t switch. The MASW-010612 is a GaAs pHEMT MMIC SP3T switch in a lead-free 1.5 mm 8-lead PDFN package. This device is ideal for low control volt

MASW-010612-TR3000 Application

• Applications
• 1.8 V Operation with 1.8 V on Voltage Pull Up
• Lead-Free 1.5 mm 8-Lead PDFN Package
• Halogen-Free ―Green‖ M

TAGS

MASW-010612-TR3000

MA-COM
