MSA1215D-3W, MSA0505D-3W, (MSA Series) DUAL/SINGLE OUTPUT DIP DC-DC CONVERTER

MSA_(M)D-3W & MSB_(M)D-3W Series 3W, WIDE INPUT, ISOLATED & REGULATED DUAL/SINGLE OUTPUT DIP DC-DC CONVERTER multi-country patent protection .

datasheet Preview Page 1 from Datasheet4u.com

MSA0505D-3W_MORNSUN.pdf

MSA1215D-3W Datasheet Preview — This datasheet PDF includes multiple part numbers: MSA1215D-3W, MSA0505D-3W. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

MSA1215D-3W, MSA0505D-3W

Manufacturer:

MORNSUN

File Size:

156.65 KB

Description:

(MSA Series) DUAL/SINGLE OUTPUT DIP DC-DC CONVERTER

Note:

This datasheet PDF includes multiple part numbers: MSA1215D-3W, MSA0505D-3W.
Please refer to the document for exact specifications by model.

Features

* Wide (2:1) input range
* Efficiency up to 82%
* Operating temperature: -40°C ~ +85°C
* 1500VDC isolation
* Short circuit protection(Automatic recovery)
* Internal SMD construction
* No heat sink required
* No external component required
* UL94-V0 package
* I

Applications

* The MSA_(M)D-3W &MSB_(M)D-3W Series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board. These products apply to: 1) Where the voltage of the input power supply is wid
