MSA0505D-3W - (MSA Series) DUAL/SINGLE OUTPUT DIP DC-DC CONVERTER

MSA0505D-3W Description

MSA_(M)D-3W & MSB_(M)D-3W Series 3W, WIDE INPUT, ISOLATED & REGULATED DUAL/SINGLE OUTPUT DIP DC-DC CONVERTER multi-country patent protection .

MSA0505D-3W Features

* Wide (2:1) input range
* Efficiency up to 82%
* Operating temperature: -40°C ~ +85°C
* 1500VDC isolation
* Short circuit protection(Automatic recovery)
* Internal SMD construction
* No heat sink required
* No external component required
* UL94-V0 package
* I

MSA0505D-3W Applications

* The MSA_(M)D-3W &MSB_(M)D-3W Series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board. These products apply to: 1) Where the voltage of the input power supply is wid

📥 Download Datasheet

Preview of MSA0505D-3W PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
MSA0505D-3W
Manufacturer
MORNSUN
File Size
156.65 KB
Datasheet
MSA0505D-3W_MORNSUN.pdf
Description
(MSA Series) DUAL/SINGLE OUTPUT DIP DC-DC CONVERTER
