MSA0515D-3W Datasheet, converter equivalent, MORNSUN

MSA0515D-3W Features

• Converter
• Wide (2:1) input range
• Efficiency up to 82%
• Operating temperature: -40°C ~ +85°C
• 1500VDC isolation
• Short circuit protection(Automatic r

PDF File Details

Part number:

MSA0515D-3W

Manufacturer:

MORNSUN

File Size:

156.65kb

Download:

📄 Datasheet

Description:

(msa series) dual/single output dip dc-dc converter.

MSA0515D-3W Application

• Applications The MSA_(M)D-3W &MSB_(M)D-3W Series are specially designed for applications where a wide range input voltage power supplies are isolate
