DS33Z44

The DS33Z44 is Quad Ethernet Mapper designed by Maxim Integrated Products.

Product Overview

Maxim Integrated Products

Datasheet Details

Part number	DS33Z44
Manufacturer	Maxim Integrated Products
File Size	1.05 MB
Description	Quad Ethernet Mapper
Datasheet	DS33Z44_MaximIntegratedProducts.pdf
Additional preview pages of the DS33Z44 datasheet.

Product details

Description

The DS33Z44 extends four 10/100 Ethernet LAN segments by encapsulating MAC frames in HDLC or X.86 (LAPS) for transmission over four PDH/TDM data streams.

Features

Four 10/100 IEEE 802.3 Ethernet MACs (MII and RMII) Half/Full Duplex with Automatic Flow Control Four 52Mbps Synchronous TDM Serial Ports with independent transmit and receive timing. HDLC/LAPS Encapsulation with Programmable FCS and Interframe Fill Committed Information Rate Controllers Provide Fractional Allocations in 512kbps Increments Programmable BERT for Serial (TDM) Interfaces External 16MB, 100MHz SDRAM Buffering Parallel Microprocessor Interface SPI Interface and Hardware Mode fo.
