MAX3600 Datasheet, Driver, Maxim Integrated Products

MAX3600 Features

• Driver S Integrates Four Current-Output Laser Drivers S Compatible with Red, Blue, and Green Lasers S 10-Bit Video DACs, fCLK = 1MHz to 160MHz S 8-Bit Gain and Offset DACs S 2ns Output Sw

PDF File Details

Part number:

MAX3600

Manufacturer:

Maxim Integrated ↗ Products

File Size:

1.15MB

Download:

📄 Datasheet

Description:

Laser driver. The MAX3600 laser driver for projectors supports video imaging with red, blue, and green lasers. Each output includes a 10-bit video

MAX3600 Application

• Applications RGB Pico Laser Projector Up to WXGA and 1080p Resolution Projectors Monochrome Blue, Green, or Red Pico Laser Projector Ordering Infor
