MAX225 Datasheet, Drivers/receivers, Maxim

MAX225 Features

• Drivers/receivers Saves Board Space
• Integrated Charge Pump Circuitry
• Eliminates the Need for a Bipolar ±12V Supply
• Enables Single Supply Operation from +5V Supply

PDF File Details

Part number:

MAX225

Manufacturer:

Maxim

File Size:

376.30kb

Download:

📄 Datasheet

Description:

+5v-powered / multichannel rs-232 drivers/receivers. The MAX220  –MAX249 family of line drivers/receivers is intended for all EIA/TIA-232E and V.28/V.24 communications inte

MAX225 Application

• Applications where ±12V is not available. The MAX225, MAX233, MAX235, and MAX245/MAX246/ MAX247 use no external components and are recommended for a
