MAX3510 Datasheet, Amplifier, Maxim

MAX3510 Features

• Amplifier o Ultra-Low Power-Up/Down Transients, 7mV Typical at 59dBmV Output o Single +5V Supply o Output Level Ranges from <8dBmV to 64dBmV o Gain Programmable in 1dB Steps o Low Transmit Output

PDF File Details

Part number:

MAX3510

Manufacturer:

Maxim

File Size:

147.09kb

Download:

📄 Datasheet

Description:

Upstream catv amplifier. The MAX3510 is a programmable power amplifier for use in CATV upstream applications. The device outputs up to 64dBmV (continuous wave

MAX3510 Application

• Applications The device outputs up to 64dBmV (continuous wave) through a 2:1 (voltage ratio) transformer. It features variable gain controlled by a
