27C16A

16K (2K x 8) CMOS EEPROM

27C16A Features

* Fast Read Access Time

* 150 ns

* CMOS Technology for Low Power Dissipation - 30 mA Active - 100 µA Standby

* Fast Byte Write Time

* 200 µs or 1 ms

* Data Retention >200 years

* High Endurance - Minimum 104 Erase/Write Cycles

* Automatic W

27C16A General Description

The Microchip Technology Inc. 28C16A is a CMOS 16K non-volatile electrically Erasable PROM. The 28C16A is accessed like a static RAM for the read or write cycles without the need of external components. During a “byte write”, the address and data are latched internally, freeing the microprocessor ad.

27C16A Datasheet (64.66 KB)

Preview of 27C16A PDF

Datasheet Details

Part number:

27C16A

Manufacturer:

Microchip ↗ Technology

File Size:

64.66 KB

Description:

16k (2k x 8) cmos eeprom.
