DSA1213, DSA1202 - High Performance Differential MEMS Oscillators

Microchip

DSA1213 Datasheet Preview — This datasheet PDF includes multiple part numbers: DSA1213, DSA1202. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	DSA1213, DSA1202
Manufacturer	Microchip ↗
File Size	1.52 MB
Description	High Performance Differential MEMS Oscillators
Datasheet	DSA1202-Microchip.pdf
Note	This datasheet PDF includes multiple part numbers: DSA1213, DSA1202. Please refer to the document for exact specifications by model.

DSA1213 Product details

Description

The DSA12x2/3/4 family of high performance oscillators utilizes the latest generation of silicon MEMS technology that reduces close-in noise and provides excellent jitter and stability over a wide range of supply voltages and temperatures.

Features

Automotive AEC-Q100 Qualified.
Any Frequency between 2.5 MHz and 450 MHz.
Supports LVPECL, LVDS, or HCSL Differential Outputs.
Very Low RMS Phase Jitter:.
