PIC24FJ32GP202 datasheet preview
PIC24FJ32GP202 page 2
Page 2
PIC24FJ32GP202 page 3
Page 3

PIC24FJ32GP202 Key Features

  • USB v2.0 On-The-Go (OTG)
  • Dual Role Capable
  • Can Act as either Host or Device
  • Low-Speed (1.5 Mb/s) and Full-Speed (12 Mb/s) USB Operation in Host mode
  • Full-Speed USB Operation in Device mode
  • High-Precision PLL for USB
  • USB Device mode Operation from FRC Oscillator
  • No Crystal Oscillator Required
  • Supports Up to 32 Endpoints (16 bidirectional)
  • USB module can use any RAM location on the device as USB endpoint buffers

Related Microchip Technology Datasheets

Part Number Description
PIC24FJ32GP203 16-Bit eXtreme Low-Power Microcontrollers
PIC24FJ32GP205 16-Bit eXtreme Low-Power Microcontrollers
PIC24FJ32GA102 16-Bit General Purpose Flash Microcontrollers
PIC24FJ32GA104 16-Bit General Purpose Flash Microcontrollers
PIC24FJ32GB002 16-Bit Flash Microcontrollers

PIC24FJ32GP202 Description

PIC24FJ64GP205/GU205 Family 16-Bit eXtreme Low-Power Microcontrollers with USB in Low Pin Count Packages High-Performance CPU Modified Harvard Architecture 64 Kbytes of Flash Memory 8 Kbytes of SRAM Up to 16 MIPS Operation @ 32 MHz 8 MHz Fast RC (FRC) Internal Oscillator: 96 MHz PLL option Multiple clock divide options Fast start-up 17-Bit x 17-Bit Single-Cycle Hardware Fractional/Integer Multiplier 32-Bit by 16-Bit...
