MT28F008B3 - FLASH MEMORY

MT28F008B3 MT28F800B3 T B None ET VG WG SG The MT28F008B3 (x8) and MT28F800B3 (x16/x8) are low-voltage, nonvolatile, electrically block-erasable (flash), programmable memory devices containing 8,388,608 bits organized as 524,288 words (16 bits) or 1,048,576 bytes (8 bits).

Writing and erasing the de

MT28F008B3 Features

* Eleven erase blocks: 40-Pin 16KB/8K-word boot block (protected) Two 8KB/4K-word parameter blocks Eight main memory blocks

* Smart 3 technology (B3): 3.3V ±0.3V VCC 3.3V ±0.3V VPP application programming 5V ±10% VPP application/production programming1

* Compatible with 0.3µm
