ME401C DC-DC Converter

MExx1C Series Ver 02 MExx1C Series DC-DC Converter MExx1C Series is a VFM Step-up DC/DC converter IC with ultra-low supply current by CMOS process. High frequency noise that occurs during switching is reduced by using advanced circuit designed, output voltage is programmable in 0.1V steps between 2.0~7.0V. A low ripple, high efficiency step-up DC/DC converter for MExx1C can be constructed of with only three external components. Also available is a CE(chip enable) function that reduce power diss.

ME401C Features

* Ultra low ripple and noise；

* Low input current：6µA(Type)；

* Operating voltage range：0.9V~6.5V；

* Output voltage range：2.0V~7.0V(step 0.1V)；

* Output voltage accuracy：±2.5%；

* Output Current：if Vin=3.0V and Vout=3.3V，then Iout=250mA；

* Low st

ME501C-Microne.pdf

ME401C Datasheet Preview — This datasheet PDF includes multiple part numbers: ME401C, ME501C. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

ME401C, ME501C

Manufacturer:

Microne

File Size:

276.08 KB

Description:

Dc-dc converter.

Note:

This datasheet PDF includes multiple part numbers: ME401C, ME501C.
Please refer to the document for exact specifications by model.
