QCN-27 Datasheet, Splitter/combiner, Mini-Circuits

QCN-27 Features

• Splitter/combiner
• low insertion loss, 0.4 dB typ.
• high isolation, 26 dB typ.
• wrap-around terminal for excellent solderability
• ultra small, 0.12"X0.06"X0.035"

PDF File Details

Part number:

QCN-27

Manufacturer:

Mini-Circuits

File Size:

282.57kb

Download:

📄 Datasheet

Description:

Power splitter/combiner.

QCN-27 Application

• Applications
• PCS/DCS
• MMDS
• ISM
• balanced amplifiers
• modulators Electrical Specifications Generic p
