MT8931B - Subscriber Network Interface Circuit

Product Overview

Mitel Networks

Datasheet Details

Part number	MT8931B
Manufacturer	Mitel Networks
File Size	61.40 KB
Description	Subscriber Network Interface Circuit
Datasheet	MT8931B Datasheet
Additional preview pages of the MT8931B datasheet.

Product details

Description

The MT8931B Subscriber Network Interface Circuit (SNIC) implements the CCITT I.430 and ANSI T1.605 Recommendations for the ISDN S and T reference points. Complete loopback testing capabilities h n n s e g On chip HDLC D-channel protocoller i ta m s a 8 bit Motorola/Intel microprocessor interface

Features

CCITT I.430 and ANSI T1.605 S/T interface Full-duplex 2B+D, 192 kbit/s transmission Link activation/deactivation D-channel access contention resolution Point-to-point, point-to-multipoint and star conﬁgurations Master (NT)/Slave (TE) modes of operation Exceeds loop length requirements ISSUE 2 August 1993 Ordering Information MT8931BC 28 Pin Ceramic DIP MT8931BE 28 Pin Plastic DIP MT8931BP 44 Pin PLCC -40°C to +85°C Descrip.
