MITSUBISHI Nch POWER MOSFET FS50UM-06 HIGH-SPEED SWITCHING USE FS50UM-06 OUTLINE DRAWING 10.5MAX.
r 3.2 7.0 Dimensions in mm 4.5 1.3 16 f 3.6 3.8MAX.
1.0 12.5MIN.
0.8 D 0.5 4.5MAX.
2.54 2.54 2.6 q w e wr q GATE w DRAIN e SOURCE r DRAIN e ¡10V DRIVE ¡VDSS 60V ¡rDS (ON) (MAX) 22m Ω ¡ID 50A ¡Integrated Fast Recovery Diode (TYP.) 65ns q TO-220 APPLICATION Motor control, Lamp control, Solenoid control DC-DC converter, etc.
MAXIMUM RATINGS Symbol VDSS VGSS ID IDM IDA IS ISM PD
