M62715

VOLTAGE DETECTING / SYSTEM RESETTING IC

Mitsubishi

M62715 Features

* Detecting Voltage M627X2,M627X3 …… 2.87V M627X4,M627X5 …… 2.58V M627X6,M627X7 …… 2.39V M627X8,M627X9 …… 1.72V

* Hysterisis Voltage ………………………… 80mV

* Delay Time M6270X ………… 0sec M6271X ………… 200 µsec M6272X ………… 50msec M6273X ………… 100msec M6274X ………… 200msec

* Few ext

M62715 General Description

The M627XXML/SL is a voltage threshold detector designed for detection of a supply voltage and generation of a system reset pulse for almost all logic circuits such as microprocessor. It also has extensive applications including battery checking, level detecting and waveform shaping circuits. FEATUR.

M62715 Datasheet (21.60 KB)
