MC10ELT20, MC100ELT20 - TTL to Differential PECL Translator

Motorola

📥 Download Datasheet

MC10ELT20 Datasheet Preview — This datasheet PDF includes multiple part numbers: MC10ELT20, MC100ELT20. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	MC10ELT20, MC100ELT20
Manufacturer	Motorola
File Size	80.11 KB
Description	TTL to Differential PECL Translator
Datasheet	MC100ELT20-Motorola.pdf
Note	This datasheet PDF includes multiple part numbers: MC10ELT20, MC100ELT20. Please refer to the document for exact specifications by model.

MC10ELT20 Product details

Description

PIN Q D VCC GND

Features

The ELT20 is available in both ECL standards: the 10ELT is compatible with positive MECL 10H logic levels while the 100ELT is compatible with positive ECL 100K logic levels.
1.5ns Typical Propagation Delay.
Differential PECL Outputs.
Small Outline SOIC Package.
PNP TTL Inputs for Minimal Loading.
Flow Through Pinouts LOGIC.
