MC13020 - AM STEREO DECODER

Product Overview

Motorola

Part number	MC13020
Manufacturer	Motorola
File Size	175.35 KB
Description	AM STEREO DECODER
Datasheet	MC13020 Datasheet
Additional preview pages of the MC13020 datasheet.

in Figure 9 may be added. Once Pin 9 goes high, the Pilot Decoder starts counting. If no pilot is detected for seven consecutive counts, it is assumed to be a good monaural station and the decoder is switched to the long count. This reduces the possibility of false stereo triggering due to signal level fluctuation or noise. If the PLL goes out of lock, or interference is detected by the co.
channel protection circuit before seven cycl.
