1N5913B Datasheet - MotorolaInc

1N5913B - Zener Voltage Regulator Diodes

MOTOROLA SEMICONDUCTOR TECHNICAL DATA 1 to 3 Watt DO-41 Surmetic 30 Zener Voltage Regulator Diodes GENERAL DATA APPLICABLE TO ALL SERIES IN THIS GROUP GENERAL DATA 1 3 WATT DO-41 SURMETIC 30 1 TO 3 WATT ZENER REGULATOR DIODES 3.3 400 VOLTS 1 to 3 Watt Surmetic 30 Silicon Zener Diodes .

.

.

a complete series of 1 to 3 Watt Zener Diodes with limits and operating characteristics that reflect the superior capabilities of silicon-oxide-passivated junctions.

All this in an axial-le

1N5913B Features

* Surge Rating of 98 Watts @ 1 ms

* Maximum Limits Guaranteed On Up To Six Electrical Parameters

* Package No Larger Than the Conventional 1 Watt Package Mechanical Characteristics: CASE: Void-free, transfer-molded, thermosetting plastic FINISH: All external surfaces are cor

1N5913B_MotorolaInc.pdf

Preview of 1N5913B PDF
1N5913B Datasheet Preview Page 2 1N5913B Datasheet Preview Page 3

Datasheet Details

Part number:

1N5913B

Manufacturer:

MotorolaInc

File Size:

156.59 KB

Description:

Zener voltage regulator diodes.
