Additional preview pages of the NL10276AC30-04D datasheet.

Product details

Description

The NL10276BC30-04D is a TFT (thin film transistor) active-matrix color liquid crystal display (LCD) comprising an amorphous silicon TFT attached to each signal electrode, a driving circuit, and a backlight.

Features

LVDS interface (adapted the THC63LVDF64A, Thine Electronics, Inc. as a receiver).
Wide viewing angle (with Retardation Film).
High luminance (350 cd/m2 at IL = 6 mArms/lamp).
Low reflection.
Incorporated edge-type backlight (four lamps/two holders).
Replaceable lamp holders (part No. 150LHS12).
Recommended inverter: Part No. 150PW081.
