NE1101B, NE1101A - High Performance Green Mode PWM controller

Datasheet Details

Part number	NE1101B, NE1101A
Manufacturer	NEM
File Size	857.71 KB
Description	High Performance Green Mode PWM controller
Datasheet	NE1101A-NEM.pdf
Note	This datasheet PDF includes multiple part numbers: NE1101B, NE1101A. Please refer to the document for exact specifications by model.

The NE1101A/B is a current mode controller which contains advanced

to meet the stringent worldwide green energy requirements. Among the advanced energy saving functionalities include the NE1101A/B include a low leakage high voltage startup current source that minimize no load standby power losses It has a PFC VCC pin which is capable of delivering 35mA to the front stage PFC controller. This bias will cut off automatically when the IC enters Green mode under light load. This feature simplifies the PFC circuit design and reduces power losses Under light load, th.
