TD1311ALF-4

Tuner module

TD1311ALF-4 Features

* www.DataSheet4U.com

* Highly integrated RF-module, 3-band tuner plus active loopthrough

* +5V supply voltage only; no external tuning voltage required

* Tuners for horizontal and vertical mounting available

* Option with DC

* power output through input conne

TD1311ALF-4 General Description

TD1600ALF-4 belong to the new generation of terrestrial tuners designed to cope with digital COFDM and analog transmission standards. From function point-of-view these tuners can be divided into two high-frequency sections, a RF-loopthrough and a single conversion tuner part. In the loopthrough sect.

TD1311ALF-4 Datasheet (535.14 KB)

Preview of TD1311ALF-4 PDF

Datasheet Details

Part number:

TD1311ALF-4

Manufacturer:

NXP ↗ Semiconductors

File Size:

535.14 KB

Description:

Tuner module.
