BAV23 - Dual high-voltage switching diodes

Product Overview

NXP

📥 Download Datasheet

BAV23 Dual high-voltage switching diodes by NXP - Datasheet Preview — Datasheet preview – BAV23

Datasheet Details

Part number	BAV23
Manufacturer	NXP
File Size	107.91 KB
Description	Dual high-voltage switching diodes
Datasheet	BAV23 Datasheet
Additional preview pages of the BAV23 datasheet.

Product details

Description

Dual high-voltage switching diodes, encapsulated in small Surface-Mounted Device (SMD) plastic packages.

Features

High switching speed: trr  50 ns.
Low leakage current.
Repetitive peak reverse voltage: VRRM  250 V.
Low capacitance: Cd  2 pF.
Small SMD plastic package 1.3.
