BT150S-500R - SCR

NXP

📥 Download Datasheet

BT150S-500R Datasheet Preview — Preview of BT150S-500R PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	BT150S-500R
Manufacturer	NXP ↗
File Size	182.78 KB
Description	SCR
Datasheet	BT150S-500R_PhilipsSemiconductors.pdf

BT150S-500R Product details

Description

Planar passivated SCR with sensitive gate in a SOT78 (TO-220AB) plastic package.

Features

Sensitive gate.
Planar passivated for voltage ruggedness and reliability.
Direct triggering from low power drivers and logic ICs 3.
