LPC4313

32-bit ARM Cortex-M4/M0 MCU

LPC4313 Features

* Cortex-M4 Processor core

* ARM Cortex-M4 processor (version r0p1), running at frequencies of up to 204 MHz.

* Built-in Memory Protection Unit (MPU) supporting eight regions.

* Built-in Nested Vectored Interrupt Controller (NVIC).

* Hardware floating-point unit.

* Non-maskab

LPC4313 General Description

The LPC435X_3X_2X_1X are ARM Cortex-M4 based microcontrollers with Floating Point Unit (FPU) for embedded applications which include an ARM Cortex-M0 coprocessor, up to 1 MB of flash and 136 kB of on-chip SRAM, 16 kB of EEPROM memory, two high-speed USB controllers, Ethernet, LCD, an external memory.

LPC4313 Datasheet (7.18 MB)

Preview of LPC4313 PDF

Datasheet Details

Part number:

LPC4313

Manufacturer:

NXP ↗

File Size:

7.18 MB

Description:

32-bit arm cortex-m4/m0 mcu.
LPC435x/3x/2x/1x 32-bit ARM Cortex-M4/M0 MCU; up to 1 MB flash and 136 kB SRAM; Ethernet, two High-speed USB, LCD, EMC Rev. 5.4

* 10 January.
