PBYL2525CT Datasheet - NXP

PBYL2525CT Rectifier diodes Schottky barrier

Dual schottky rectifier diodes intended for use as output rectifiers in low voltage, high frequency switched mode power supplies. The PBYL2525CT series is supplied in the SOT78 (TO220AB) conventional leaded package. The PBYL2525CTB series is supplied in the SOT404 surface mounting package. PINNING .

PBYL2525CT Features

* Low forward volt drop

* Fast switching

* Reverse surge capability

* High thermal cycling performance

* Low thermal resistance PBYL2525CT, PBYL2525CTB series SYMBOL QUICK REFERENCE DATA VR = 20 V/ 25 V IO(AV) = 25 A VF ≤ 0.43 V a1 1 k 2 a2 3 GENERAL DES

PBYL2525CT_PhilipsSemiconductors.pdf
