PCA9512B - Level shifting hot swappable I2C-bus and SMBus bus buffer

Product Overview

📥 Download Datasheet

Datasheet preview – PCA9512B

Datasheet Details

Part number PCA9512B
Manufacturer NXP
File Size 247.06 KB
Description Level shifting hot swappable I2C-bus and SMBus bus buffer
Datasheet download datasheet PCA9512B Datasheet
Note This datasheet PDF includes multiple part numbers: PCA9512B, PCA9512A.
Please refer to the document for exact specifications by model.
Additional preview pages of the PCA9512B datasheet.

Product details

Description

The PCA9512A/B is a hot swappable I2C-bus and SMBus buffer that allows I/O card insertion into a live backplane without corruption of the data and clock buses and includes two dedicated supply voltage pins to provide level shifting between 3.3 V and 5 V systems while maintaining the best noise margin for each voltage level.
