54F244 Datasheet, Drivers, National Semiconductor

54F244 Features

• Drivers Y TRI-STATE outputs drive bus lines or buffer memory address registers Y Outputs sink 64 mA (48 mA mil) Y 12 mA source current Y Input clamp diodes limit high-speed termination effects

PDF File Details

Part number:

54F244

Manufacturer:

National Semiconductor

File Size:

386.47kb

Download:

📄 Datasheet

Description:

Octal buffers/line drivers. The ’F240 ’F241 and ’F244 are octal buffers and line drivers designed to be employed as memory and address drivers clock drivers and
