OSD32MP157C Product details

Description

17 5.2 Reserved Balls 22 5.3 Test Point Signals 22 6 OSD32MP15x Components 23 6.1 STM32MP15x Processor 24 6.1.1 I/O Voltages 24 6.2 DDR3L Memory 24 6.3 MEMS Oscillators 25 6.3.1 HSE MEMS Oscillator 25 6.4 EEPROM 26 6.4.1 EEPROM Contents 26 6.4.2 EEPROM Write Protection 26 7 Power Management 27 7.1 Power Block Diagram 27 7.2 Interface between STM32MP15x and STPMIC1A 28 7.3 Power Input 28 7.3.1 VIN Power Input 28 7.3.2 VBAT Power Input 29 7.4 Optional power inputs

Features

ST STM32MP15x, DDR3L, STPMIC1A, 4KB EEPROM, Oscillator and passive components integrated into a single package.
STM32MP15x Features: o Arm® Cortex®-A7 up to 800MHz x2 o Arm® Cortex®-M4 up to 209MHz o NEON™SIMD Coprocessor x2 o Arm® TrustZone® o USB 2.0 HS + PHY x2 o Ethernet 10/100/1000 o CAN FD/TTCAN x2, UART x4, USART x4, SPI x6, I2C x6, I2S x3, QSPI x2 o eMMC/SD/SDIO Ports x3 o GPIO x148 o 24-bit RGB Display, MIPI DSI o Camera Interface o 22 Channel 16-bit ADC x2, 12-bit DA.
