FAN3268 - 2A Low-Voltage PMOS-NMOS Bridge Driver

Product Overview

ON Semiconductor

Datasheet Details

Part number	FAN3268
Manufacturer	ON Semiconductor
File Size	1.04 MB
Description	2A Low-Voltage PMOS-NMOS Bridge Driver
Datasheet	FAN3268 Datasheet
Additional preview pages of the FAN3268 datasheet.

Product details

Description

The FAN3268 dual 2 A gate driver is optimized to drive a high side P channel MOSFET and a low side N channel MOSFET in motor control applications operating from a voltage rail up to 18 V. voltage lockout function that prevents the output switching devices from operating if the VDD supply voltage is below the operat

Features

4.5 V to 18 V Operating Range.
Drives High.
Side PMOS and Low.
Side NMOS in Motor Control or Buck Step.
Down.
