MC10H104 Datasheet, Gate, ON Semiconductor

MC10H104 Features

• Gate
• Propagation Delay, 1.0 ns Typical
• Power Dissipation 25 mW/Gate (same as MECL 10K)
• Improved Noise Margin 150 mV (Over Operating Voltage and Temperature Rang

PDF File Details

Part number:

MC10H104

Manufacturer:

ON Semiconductor ↗

File Size:

126.23kb

Download:

📄 Datasheet

Description:

Quad 2-input and gate. The MC10H104 is a quad 2-input AND gate. One of the gates has both AND/NAND outputs available. This MECL 10H™ part is a functional/pi
