MC10H105 Datasheet, Gate, ON Semiconductor

MC10H105 Features

• Gate
• Propagation Delay, 1.0 ns Typical
• Power Dissipation 25 mW/Gate (same as MECL 10K)
• Improved Noise Margin 150 mV (Over Operating Voltage and Temperature Rang

PDF File Details

Part number:

MC10H105

Manufacturer:

ON Semiconductor ↗

File Size:

121.32kb

Download:

📄 Datasheet

Description:

Triple 2-3-2-input or/nor gate. The MC10H105 is a triple 2-3-2-input OR/NOR gate. This MECL 10H™ part is a functional/pinout duplication of the standard MECL 10K™ fa
