MC10H641 - SINGLE SUPPLY PECL-TTL 1:9 CLOCK DISTRIBUTION CHIP

Datasheet Summary

Description

The MC10H/100H641 is a single supply, low skew translating 1:9 clock driver.

28 for optimal power pinning, signal flow through and electrical performance.

Features

a 24 mA TTL output stage, with AC performance specified into a 50 pF load capacitance. A latch is provided on.
chip. When LEN is LOW (or left open, in which case it is pulled LOW by the internal pulldown) the latch is transparent. A HIGH on the enable pin (EN) forces all outputs LOW. Both the LEN and EN pins are positive ECL inputs. The VBB output is provided in case the user wants to drive the device with a single.
ended input. For single.
ended use, the VBB should be conne.

Datasheet Details

Part number	MC10H641
Manufacturer	ON Semiconductor
File Size	163.85 KB
Description	SINGLE SUPPLY PECL-TTL 1:9 CLOCK DISTRIBUTION CHIP
Datasheet	MC10H641 Datasheet
