Quad d flip-flop.

MC74HC175A, Quad D Flip-Flop

MC74HC175A Quad D Flip-Flop with Common Clock and Reset High Performance Silicon Gate CMOS The MC74HC175A is identical in pinout to the LS175.

The device inputs are compatible with standard CMOS outputs; with pullup resistors, they are compatible with LSTTL outputs.

This device consists of four D flip flops with common Reset and Clock inputs, and separate D inputs.

Reset (active low) is asynchronous and occurs when a low level is applied to the Reset input.

Infor

MC74HC175A Features

* Output Drive Capability: 10 LSTTL Loads

* Outputs Directly Interface to CMOS, NMOS, and TTL

* Operating Voltage Range: 2.0 to 6.0 V

* Low Input Current: 1 mA

* High Noise Immunity Characteristic of CMOS Devices

* In Compliance with the Requirements D
