MMJT350T1 Datasheet, Silicon, ON Semiconductor

✔ MMJT350T1 Features

http://onsemi.com
High Collector
Emitter Sustaining Voltage
VCEO(sus) = 300 Vdc @ IC = 1.0 mAdc Excellent DC Current Gain
hFE = 30
240 @ IC = 50 mAdc Epox

✔ MMJT350T1 Application

such as low power, line
operated series pass and switching regulators requiring PNP capability. Features ht

PDF File Details

ON Semiconductor manufacturer logo and representative part image

Part number:

MMJT350T1

Manufacturer:

ON Semiconductor ↗

File Size:

89.04kb

Download:

📄 Datasheet

Description:

Bipolar power transistors pnp silicon.

📥 Download PDF (89.04kb)
